Description
- Self-contained, double wall hung electric refrigerated, water cooler
- Capacity 8.0 GPH of 50°F drinking water, based upon 80°F inlet water and 90°F ambient
- All models have a hooded stream projector with self closing push bars on front and both right and left sides
- Flow regulator provides constant stream from 20 to 105 psi water pressure
- Bubbler orifice fully protected to meet all sanitary codes
NOTE: Minimum 40 psi supply line pressure required in special circumstances where both sides of bi-level are in use simultaneously to ensure adequate stream height. Does not apply to non-refrigerated units.
COOLING SYSTEM
- Motor Compressor: Hermetically sealed, reciprocating type, 120 Volt/60 Hz, single phase. Sealed-in lifetime oil supply. Equipped with electric cord and three prong molded rubber plug.
- Condenser: Fan cooled, copper tube with aluminum fins. Fan motor is permanently lubricated.
- Cooling Unit: Combination tube-tank type. Tube portion is continuous coil of copper tubing. Fully insulated with EPS foam which meets Underwriters Laboratories Inc. requirements for self extinguishing material.
- Refrigerant Control: Refrigerant HFC-134a is controlled by accurately calibrated capillary tube for positively trouble-free operation.
- Temperature Control: Enclosed adjustable thermostat is factory preset. Requires no adjustment other than for altitude requirements. Easily accessible.
